2 × 2 × 0.3 Pvc Coated Gabion Box Weather Proof Easy Installation

  • 1
  • 2

Brand Name : SHUXIN

Model Number : SX-GWC

Certification : ISO, CE, SASO,CO,COC,PVOC

Place of Origin : HB

MOQ : 1000 ㎡

Price : Negotiated

Payment Terms : L/C, T/T, Western Union, MoneyGram, Trade Assurance, Paypal

Supply Ability : 5000 Tons per year

Delivery Time : 15 Working Days

Packaging Details : In Bundle or According to Customer Request

Material : 10% Aluminum - Zinc Alloy Wire

Mesh Hole : 80*100mm

Division : 1 Diaphragm Every Meter

Surface Treatment : Galvanized and PVC Coated

Length : Maximum 6 M

Width : Maximum 3 M

Contact Now

PVC Coated 2 × 2 × 0.3M Gabion Wire Mesh Cage Wall

The is a structure made of hexagonal double twisted wire mesh. es are filled with stones at the project site to form flexible and permeable, monolithic structures such as river bank protection and channel linings for erosion control. The steel wire used to manufacture the mattress is heavily zinc-coated soft temper steel. The standard combinations of mesh is shown in Table. In order to reinforce the structure, all mesh panel edges are used with a wire having a greater diameter. es are uniformely divided into partitioned cells by internal diaphragms.

Wire Thickness Specification:

Mesh type 8*10cm 6*8cm
Characteristics Metallic coated PVC coated Metallic coated PVC coated
Mesh openings 83mm x 114mm 83mm x 114mm 64mm x 83mm 64mm x 83mm
Mesh wire 2.7mm (0.106 in.) 3.05mm( 0.120 in.) 2.2mm (0.087 in.) 2.2mm (0.087 in.)
Selvage wire 3.4mm (0.134 in.) 3.8mm (0.150 in.) 2.7mm (0.105 in.) 2.7mm (0.105 in.)
Lacing wire 2.2mm (0.087 in.) 2.2mm (0.087 in.) 2.2mm (0.087 in.) 2.2mm(0.087 in.)

Size of Gabion Box:

Opening(mm)

Wire Diameter(Metal Wire)

mm

Wire Diameter (PVC Coated)

Inner/Outside(mm)

 Strands
60X80 2.0-2.8 2.0/3.0-2.5/3.5 3
80X100 2.0-3.2 2.0/3.0-2.8/3.8 3
80X120 2.0-3.2 2.0/3.0-2.8/3.8 3
100X120 2.0-3.4 2.0/3.0-2.8/3.8 3
100X150 2.0-3.4 2.0/3.0-2.8/3.8 3
120X150 2.0-4.0 2.0/3.0-3.0/4.0 3

Size of Gabion Mattress:

Size Notes
Length(mm) Width(mm) Height(mm) Unit volume(m³)
2.00 1.00 0.30 1 0.60
3.00 1.00 0.30 2 0.90
4.00 1.00 0.30 3 1.20
2.00 1.00 0.50 1 1.00
3.00 1.00 0.50 2 1.50
4.00 1.00 0.50 3 2.00
1.00 1.00 1.00 0 1.00
1.50 1.00 1.00 0 1.50
2.00 1.00 1.00 1 2.00
3.00 1.00 1.00 2 3.00
4.00 1.00 1.00 3 4.00

Gabion Baskets Applications:
1. Control and guide of water or flood
2. Flood bank or guiding bank
3. Preventing of rock breaking
4. Bridge Protection
5. Water and soil protection
6. Coast protection
7. Seaport engineering
8. Strengthening structure of soil
9. Protection of road

Gabion Baskets Features:

1. Economic.
2. Just fill the stone into the gabions and seal it.
3. Simple installation.
4. No special technology needed. Weather proof under natural destroy, corrosion resistant.
5. No collapse even under big scope of deforming.
6. Sludge in the stones is good for plant growing.
7. Mixed to form a integrity with the natural environment. Good permeation can prevent the damage by hydrostatic.
8. Less transport freight. It can be folded together for transport and further installation.
